Product Presentation
The Mobile Dust Removal Hopper is a mobile equipment combining material conveying and dust control functions. It is primarily used in the loading, unloading, and transfer processes of bulk materials (such as fly ash, cement, grain, and mineral powder), effectively reducing dust pollution during operations and complying with environmental protection requirements.
1. Core Functions and Characteristics of the Mobile Dust Removal Hopper
(1) Dust Removal Technology
Negative pressure vacuum: A fan or central dust removal system creates negative pressure inside the hopper to prevent dust leakage.
Filter system: Utilizes bag dust removal, filter cylinders, or wet dust removal technology to capture fine particles (PM10/PM2.5).
Sealed design: The inlet and outlet are connected via soft seals or telescopic sleeves to minimize dust dispersion.
(2) Mobility and Flexibility
Wheeled/trailer design: Equipped with brake swivel wheels or tow hooks, making it suitable for various sites (e.g., factories, docks, construction sites).
Modular structure: Some models can be folded for easy transportation and storage.
(3) Intelligent Control (Optional)
Automatic start/stop: The dust removal system activates when material flows, ensuring energy efficiency.
Remote monitoring: Provides real-time data on dust concentration and equipment status (IoT-enabled).
2.Major application scenarios of Mobile Dust Removal Hopper
|
Trade |
Typical uses |
|
Building materials/cement |
Fly ash and cement are loaded to prevent dust pollution. |
|
Grain processing |
Wheat, corn and other grain transportation to avoid dust explosion risk. |
|
Chemical/pharmaceutical |
Dust-free feeding of powder raw materials (such as calcium carbonate, titanium dioxide) |
|
Mining/ Metallurgy |
Enclosed loading and unloading of ore powder and coal powder to reduce occupational health hazards. |
|
Environmental recycling |
Dust control in construction waste sorting and biomass particle loading and unloading process. |
3.Key selection parameters of Mobile Dust Removal Hopper
|
Parameter |
Explain |
|
Process air volume |
Dust collector air volume (m³/h) is selected according to the dust characteristics of the material. |
|
Filter accuracy |
Bag/filtration cylinder grade (e.g. 0.3μm filtration efficiency ≥99%). |
|
Mobile mode |
Manual push, forklift handling or on-board (e.g. dust collector funnel mounted on a truck). |
|
power resources |
Electric (380V industrial), diesel engine (no power supply site) or pneumatic (explosion-proof environment). |
|
Load |
The hopper load (commonly 1-10 tons) matches the operation efficiency. |
4. Examples of Typical Products
Final Solution
Light Manual Dust Removal Hopper
Suitable for small-batch powder feeding (e.g., food additives).
Large Vehicle-mounted Dust Removal Hopper
Used with dump trucks for bulk cargo unloading at ports (e.g., soybeans, sulfur).
Intelligent Frequency-conversion Dust Removal Hopper
Automatically adjusts fan power based on dust concentration, ensuring energy savings and noise reduction.
